products

•

  Belt Driven Series Compressor M series

  Working Power: 5.5~75KW(7.5-100HP)
  Free Air Delivery: 0.6~13.3m³/min(21.2~469.7cfm)
  Working Pressure: 7/8/10/12.5bar(101.5/116/145/181.3 psig)

  learn more
•

  Direct Driven Seires Compressor D series

  Working Power: 15~75KW(20-100HP)
  Free Air Delivery: 2.3~13.3m³/min(81~469.7cfm)
  Working Pressure: 7/8/10bar(101.5/116/145 psig)

  learn more
•

  Large Direct Driven Series Compressor II series

  Working Powere: 90~200KW(125~270HP)
  Free Air Delivery: 12.5~35.1m³/min(441~1239.5cfm)
  Working Pressure: 7/8/10/12.5bar(101.5/116/145/181 psig)

  learn more
•

  Refrigeration Dryer(High Temp)

  lnlet Air Temperature:Rating：:65℃; Maximum:80℃
  Pressure Rating: 0.7 Mpa Applicable Range:0.3-0.95 Mpa
  Environmental Temperature： Air-cooling Type:= 2 ℃,=38℃
  Water-cooling Type:= 2 ℃;=45℃
  Pressure Dew Point: 2-10 C (0.7Mpa)
  Cooling Water Temperature:T inlet =31℃；T outlet=37℃
  Cooling Water Pressure:0.15-0.4 Mpa

  learn more
•

  Air Tank

  Design pressure: 8, 10, 13, 16, 20, 40BAR
  Design working temperature: 100 ℃
  Material: Q235B, 304 or 316 stainless steel is option, it can be customized according to requirements

  learn more
•

  Heatless Absorption Dryer

  Rating lnlet Air Temperature: ≤38℃    Rating Operating Pressure: 0.8 Mpa
  Applicable Range: 0.4-1.0 Mpa      Pressure Drop: < 0.02 Mpa
  Pressure Dew Point: -40 ℃ (0.7 Mpa)    Regeneration Mode: Heatless Regeneration
  Control Mode: Programmable Time Control
  Regeneration Air Consumption: = 12% Rating Air Capacity
  Absorbent: Active Alumina    Oil Content of Inlet Air:<0.1 mg/m³
  lnstallation Mode: lt should be installed in the concrete ground in rooms，Not need special base and the temperature is no less than 0 ℃.
  Power Consumption: 100W

  learn more
•

  Refrigeration Dryer (Normal Temp)

  Inlet air temperature: rated:38℃.highest:45℃
  Working pressure: rated 0.7 Mpa
  Ambient temperature:
  Air cooling :≥2℃≤38℃
  Water cooling:≥2℃≤45℃
  Pressure dew point: 2—10℃(0.7Mpa)
  Cooling water temperature: T inlet ≤31℃，T outlet ≤37℃
  Cooling water pressure: 0.15--0.4Mpa

  learn more
•

  High-efficiency Oil Remover

  Working pressure: 0.7 ~ 1.0MPa
  Intake temperature: 0 ~ 50 ℃
  Oil content of outlet gas: ≤0.1 ~ 0.001ppm
  Remark: The above-mentioned parameter
  pressure technical standard is 0.7MPa (other special standards can be customized)

  learn more
•

  Micro-Heat Absorption Dryer

  Rating Inlet Air Temperature: ≤38℃    Rating Operating Pressure: 0.8 Mpa
  Applicable Range: 0.4-1.0 Mpa    Pressure Drop: <0.02 Mpa
  Pressure Dew Point: -40 ℃ (0.7 Mpa)   Regeneration Mode: Micro-thermal Regeneration
  Control Mode: Programmable Time Control
  Regeneration Air Consumption: =7% Rating Air Capacity
  Sorbent: Active Alumina   Oil Content of lnlet Air:< 0.1 mg/m3
  lnstallation Mode:It should be installed in the concrete ground in rooms Not need special base and the temperature is no less than 0 ℃.

  learn more
•

  Precision Filter Series

  Medium：Compressed air or corrosion-free gases      lnlet Air Temperature：<60℃
  operating Pressure：Standard: 0.8Mpa; Maximum: 1.3 Mpa
  lnitial Pressure Drop：>0.014 Mpa
  work Life：C/T/A:8000h;H: 2000h (with the pressure drop up to 0.07 Mpa as the standard)
  Water Load：C : 25,000 ppm,T: 2,000 ppm,A: 100 ppm
  Optional Accessories：Automatic drainage system, electronic drainage system, differential pressure meter

  learn more
•

  Water Separator

  Working pressure: 0.7~1.0MPa
  lntake temperature: 0 ~65 ℃
  Filter particle size: 5μm
  Water removal rate: 298%
  Oil content of outlet gas: ≤10PPM
  Remark: The above-mentioned parameter pressure technical standard is 0.7MPa (other special standards can be customized).

  learn more
